BGA Rework Station professional rework process for free.
Welcome to my website, BGA Rework Station, the first and only real professional / world's best practice approach.
BGA Rework Stations.com, where you’ll have detailed all errors, mistakes, world’s worst ever practices, and approaches made by “well-known, professional, Chinese manufacturers,” reviewed from scientific/technological / best practice / common sense point of view. It is the only place, all over the internet, where you can learn about BGA Rework Stations. About Rework Process, Selective Soldering, Best Practices, and much more. Please be sure that you read all the information / all pages on this website, among the information on that (sister website)…
Please pay attention to the fact that in time I’ll change, / add, many things on these sites until it is the final version. I work on content structure, systemizing the information, and completing all content I’ll collect over many years. Daily will be updates, new entries, new pages, new designs, and more… So… Please be patient!
- A Bga Rework Station is not;
- Every popcorn machine.
- Every pizza machine
- Every Santa Claus cousin, which is sold all over the internet as a “Professional BGA Rework Station.”
- On this website, you can learn about what means a Real Professional BGA Rework Station, a Real Professional Rework Process, A Real Professional Selective Soldering Process/machine, and much more.
Touch the accordion title below (+ or – sign)… to expand or contract the accordion details… The accordions have only partial information here on the front/home/landing page (this actual page). Best reading experience you’ll have if you use the menu. The menu is the only way to navigate the entire website completely! On another (detailed description page), the accordion has the function of the menu or detailed description for something! Don’t forget… This site is intended to be read on PC / MAC computers and tablets, but I made some efforts to be used inclusive on smartphones; the best reader experience is on PC / MAC computers.
- Top direct electromagnetic energy transfer
- Bottom direct electromagnetic energy transfer
- PCB / board free expansion fixture (elastic)
- Temperature measurement, contact / non-contact
- Real rework process close view camera
- High performance / operator friendly software
- BGA / component placement and centering
- World level database with PCB / BGA – Chips
- Flux / flux paste / tin / balls / materials
A Top Energy Emitter assure the generation, emission, uniformity, reflection, transmission and shaping of the pure electromagnetic energy spot, that are directed to component (BGA, chips, electromagnetic shields, connectors etc.), that will be heated…
A Bottom Energy Emitter assure the generating, emission, uniformity, reflection, transmission and shaping of the pure electromagnetic energy that are directed to board / PCB, electromagnetic shields, Connectors etc. that will be heated…
The support for the board / PCB is more important that you can believe. The importance consists in two essential proprieties, high strength and elasticity. That two proprieties are only two from another many mandatory proprieties. Read more…
Infrared / Non-Contact temperature sensors (one for the component, another for the board / PCB), with high accuracy margin (max. ± 1 °C max. ideal 0.5 °C) NIST traceable certificate. Among non-contact sensors, a high quality, the lowest possible error coefficient contact sensors are mandatory on the high quality BGA Rework Process. You can read in detail why…
Real rework process close views live camera are a must, that camera is needed because until now the rework process it is unknown. With the rework process, close view camera and our / your professional experience in soldering…
High performance PID / Fuzzy Logic PID / AI assisted software it is a must to perfect control a real professional BGA Rework Station. Connections between various pieces of hardware and control them, participate at 100% repetitively of the Rework process…
Beam combiner (not stupid “Beam Splitter” because we need to combine two images in one, not “split” our eyes in two parts) are needed to center the BGA with the board… But exist another methods more performant or more simple and cheapest for that purpose…
A huge importance, it has a unified database at world level with components, boards and their parameters from temperature, shapes, dimensions etc. point of view. In fact, that database will be automatically built / developed as a real professional BGA Rework Station is used…
Flux / flux paste / tin / balls / materials, a universal datasheet standard / format, it is a must. That datasheets must be written / documented from scientifically / technologically point of view with standards at his base. Any undocumented materials / consumables must be avoided when we speak about BGA Rework Station or Rework process.
- Direct electromagnetic energy transfer
- Electromagnetic energy uniformity for BGA / Chip
- Electromagnetic energy uniformity for PCB / Board
- Ultra accurate temperature measurement
- Ultra accurate control of temperature of PCB / BGA
- Easy / operator friendly best practice approach
- Ergonomic / Easy manipulation of the tool
- 100% Repetitive perfect result, 100% yield
- Process detailed observation
Direct electromagnetic energy transfer must be used to heat BGA, components, electromagnetic shields, connectors and so on. I give you only two examples where that approach is used. The first example is the induction heating and the second is the microwave oven.
The uniform temperature across a BGA or a chip or other components, electromagnetic shields and so on assure the uniform soldering across the entire area of that. In every material exist the inertia as a major factor of uniform propagation of heat.
The uniform temperature across a BDA or a chip or other components, electromagnetic shields and so on assure the uniform soldering across the entire area of that. In every material exist the inertia as a major factor of uniform propagation of heat.
Ultra accurate temperature measurement, it is a must-have on a high quality, high performance BGA rework Station and rework process. If we think that we play in a very thin range of temperature that delimits the frontiers between success and failure of our rework process.
Among ultra accurate temperature measurement, the ultra accurate control of temperature of PCB / BGA is another must have, to achieve the 100% yield, 100% repetitiveness on our rework process with a real professional BGA Rework Station.
Easy / operator friendly best practice approach continue the list of must-have attributes that our real professional BGA rework Station must have. This is very important when we speak about the human resource available at our disposition.
The ergonomic / easy manipulation of the tool, of course it is included on our list that a real professional BGA Rework Station must have. We need easy access from all sides to our work space, in special cases we even need to easily move our real professional BGA Rework station.
100% Repetitive perfect result, 100% yield, must be the only acceptable result for a real professional BGA Rework Station. It is not important in what place in the world, that goal is a must-have. It is inadmissible from a best practice point of view the fact that can exist any variation on the success of a rework process below that perfect when we’ll speak about professionality.
Process view in real time. Detailed observation of the rework process corroborated with the accurate monitoring of the process, all synchronized in a visual manner, give us the possibility to post analyze the rework process, from practically, scientifically and technologically point of view.
